Last updated 01 May 2026
Lift up to 2.5 tonnes with this tough, low-maintenance, Lithium-ION powered electric forklift
Balanced and versatile. That’s the essence of the new and improved Baoli KBE 20-25 series 1293 electric forklift (formerly 6091 series). It brings together a tough and reliable counterbalance forklift in an energy-efficient and budget-friendly package.
Already sold? Check out the full specs and enquire today by visiting our dedicated KBE25 page.
Want to learn more first? Read on below.
KBE 20-25 Electric Forklift Performance
Featuring a lift capacity of 2.0 – 2.5 tonnes, the Baoli KBE series forklifts are built to deliver high performance and productivity – inside or out. They’re also designed to lower operating costs with an ideal balance of low energy consumption and maintenance needs, so you get the best of both worlds.
Baoli KBE Forklift Comfort
In addition to their reliable performance, the KBE 20-25 series forklifts have been built for operator comfort.
Lots of thought has been put into giving operators an ergonomically designed cab for fatigue-free work which includes:
- A fully suspended spacious driver’s cabin
- A large comfortable footwell
- Adjustable steering column
- A fully suspended, adjustable comfort seat
- Lots of storage compartments
Thanks to the hydraulic damping mounts the spacious cabin is isolated from vibration, noise and shock.
The combination of the forklift’s compact steering wheel, adjustable steering column and hydraulic steering system, gives the driver an easier and more comfortable steering experience than ever before.
Baoli Forklift Safety
When it comes to safety, the KBE 20-25 series is everything you would expect from a Baoli forklift backed by Linde Material Handling Australia. The KBE series gives operators an optimal view of the forklift’s load and travel path, thanks to its optimised visibility design. In addition, this electric forklift features Linde Curve Assist, which regulates its cornering speed, automatically monitoring the steering angle which reduces the forklift’s speed, minimising the chance of tipping. Finally, its large step-in plate also features an anti-slip design, making it safe both under cover or outside in wet weather.
KBE25 Electric Forklift Full Specifications
Here's a complete breakdown of what the KBE 20-25 delivers across both the 2.0 tonne and 2.5 tonne variants.
| Specification | KBE20-Li-01 (2.0t) | KBE25-Li-01 (2.5t) |
|---|---|---|
| Rated capacity | 2,000 kg | 2,500 kg |
| Load centre distance | 500 mm | 500 mm |
| Wheelbase | 1,495 mm | 1,495 mm |
| Service weight | 3,310 kg | 4,105 kg |
| Axle load laden (front/rear) | 4,720 / 590 kg | 5,870 / 735 kg |
| Tyre type | Pneumatic | Pneumatic |
| Tyre size front | 23x9-10 | 23x9-10 |
| Tyre size rear | 18x7-8 | 18x7-8 |
| Mast tilt forward/backward | 6° / 10° | 6° / 10° |
| Mast lowered height | 2,070 mm | 2,068 mm |
| Standard lift height | 3,000 mm | 3,000 mm |
| Mast extended height | 4,045 mm | 4,045 mm |
| Overhead guard height | 3,370 mm | 3,370 mm |
| Overall width | 1,265 mm | 1,265 mm |
| Ground clearance (wheelbase) | 120 mm | 120 mm |
| Turning radius | 2,046 mm | 2,046 mm |
| Aisle width — 1000x1200 crossways | 3,710 mm | 3,710 mm |
| Aisle width — 800x1200 lengthways | 3,910 mm | 3,910 mm |
| Travel speed (laden/unladen) | 15 / 15 km/h | 15 / 15 km/h |
| Lift speed (laden/unladen) | 0.33 / 0.38 m/s | 0.28 / 0.38 m/s |
| Max. gradeability (laden/unladen) | 18% / 20% | 18% / 20% |
| Drive motor | 10.2 kW | 10.2 kW |
| Lift motor | 11.5 kW | 11.5 kW |
| Battery voltage / capacity (Li-ion) | 51.2V / 412Ah | 51.2V / 412Ah |
| Battery voltage / capacity (lead-acid) | 48V / 600Ah | 48V / 600Ah |
| Sound level at operator | 67 dB(A) | 67 dB(A) |
KBE 20-25 Warehouse Forklift Mast Options: Choosing the Right Lift Height
The KBE 20-25 is available across a wide range of mast configurations to suit different racking heights and building clearances. The lowered mast height is the critical number to check against any doorway or overhead clearance in your facility.
| Mast Type | Lift Height | Retracted Height | Free Lift | Extended Height |
|---|---|---|---|---|
| Standard | 3,000 mm | 2,070 mm | 150 mm | 4,045 mm |
| Standard | 3,300 mm | 2,220 mm | 150 mm | 4,345 mm |
| Standard | 3,500 mm | 2,320 mm | 150 mm | 4,545 mm |
| Standard | 4,000 mm | 2,620 mm | 150 mm | 5,045 mm |
| Standard | 4,500 mm | 2,870 mm | 150 mm | 5,545 mm |
| Standard | 5,000 mm | 3,120 mm | 150 mm | 6,045 mm |
| Standard | 5,500 mm | 3,420 mm | 150 mm | 6,545 mm |
| Duplex | 3,000 mm | 2,036 mm | 1,385 mm | 4,045 mm |
| Duplex | 4,000 mm | 2,586 mm | 2,586 mm 1,935 mm | 5,045 mm |
| Duplex | 4,500 mm | 2,836 mm | 2,185 mm | 5,545 mm |
| Triplex | 4,100 mm | 1,986 mm | 1,335 mm | 5,145 mm |
| Triplex | 5,000 mm | 2,336 mm | 1,685 mm | 6,045 mm |
| Triplex | 5,500 mm | 2,586 mm | 1,935 mm | 6,545 mm |
| Triplex | 6,000 mm | 2,836 mm | 2,185 mm | 7,045 mm |
| Triplex | 6,500 mm | 3,036 mm | 2,385 mm | 7,545 mm |
The duplex and triplex mast options provide free lift, meaning the forks rise to a useful height before the outer mast sections begin to extend. This is particularly valuable in height-restricted environments where you still need maximum lift capability.
The Baoli KBE 20-25 Comes with Two Battery Options to Suit Your Operation
With two battery configurations, you get the flexibility to match the machine to your shift pattern and operational demands.
The lead-acid option (48V / 600Ah) is a proven, cost-effective choice for single-shift operations with overnight charging.
The lithium-ION option (51.2V / 412Ah) is the better fit for multi-shift environments. This electric forklift is fully maintenance-free, supports opportunity charging during breaks and between shifts, and delivers a longer overall service life with no watering or equalisation charges required.
Both variants use Italian-made AC motors with regenerative braking technology, which recovers energy during braking and mast lowering to extend runtime and reduce overall energy consumption, a big advantage in high-cycle operations.
The KBE 202-25 is Built for Outdoors: Pneumatic Tyres and Real Ground Clearance
Pneumatic tyres on both the 2.0 tonne and 2.5 tonne variants provide the grip, cushioning, and surface adaptability that polyurethane-tyred warehouse machines simply can't match on outdoor surfaces. Combined with 120mm of ground clearance at the wheelbase and a maximum gradeability of 18% laden and 20% unladen, the KBE 20-25 handles outdoor sealed yards, loading areas, ramps, and light uneven surfaces with confidence.
For operations that move between indoor and outdoor environments throughout the day like manufacturing facilities, building suppliers, food production sites, and mixed-use distribution centres, the KBE 20-25 can handle it, it is a versatile single-machine solution.
Linde Curve Assist: Automatic Cornering Safety
One of the KBE 20-25's standout safety features is Linde Curve Assist, which automatically monitors the steering angle as the machine corners and reduces travel speed accordingly. This significantly lowers the risk of tipping when carrying loads through turns, particularly important in busy yard environments or when travelling at speed between locations.
Is the KBE 20-25 Right For Your Operation?
A great fit if you:
- Need 2.0 or 2.5 tonne lift capacity for standard to heavy pallet handling
- Operate in mixed indoor and outdoor environments: Pneumatic tyres and 120mm ground clearance handle outdoor sealed surfaces confidently
- Want a zero-emission alternative to LPG or diesel for indoor or enclosed spaces
- Need flexible mast options ranging from 3,000mm up to 7,545mm extended height
- Want Italian-made AC motors with regenerative braking for lower energy costs and longer runtime
- Prefer the flexibility of choosing between lead-acid and lithium-ION battery configurations
May not suit you if you:
- Need more than 2.5 tonne capacity: A larger counterbalance forklift would be required
- Operate regularly on heavily uneven, muddy, or rough off-road terrain: A diesel or LPG counterbalance forklift would be more appropriate
- Run very high-intensity continuous multi-shift operations where LPG's unlimited runtime is a priority
Looking for an electric forklift for sale? You can get an incredible deal right now. Get the KBE25 2.5 tonne electric forklift for $29,990 excl. GST or rent-to-own for $144p/w with a 5-year warranty! Click the button below to get this deal.
Frequently Asked KBE 20-25 Electric Forklift Questions
Question
What is the lifting capacity of the Baoli KBE 20-25 electric forklift?
The KBE 20-25 can lift loads from 2.0-2.5 tonnes.
What type of battery does the Baoli KBE 20-25 electric forklift come with?
The KBE 20-25 is available with two battery options depending on your operational needs. The standard lead-acid option (48V / 600Ah) is a reliable, cost-effective choice well suited to single-shift operations with overnight charging. The lithium-ION option (51.2V / 412Ah) is available for operations that need more flexibility. It's maintenance-free, supports opportunity charging during breaks and between shifts, and offers a longer service life with no watering or equalisation charges required.
Both options are paired with Italian-made AC motors and regenerative braking technology to maximise energy efficiency and runtime.
What is the Baoli KBE 20-25 electric forklift best used for?
The Baoli KBE 20-25 electric counterbalance forklift is best suited to small and medium-sized businesses that need a capable, zero-emission machine for both indoor and outdoor use.
With lift capacities of 2.0 and 2.5 tonnes, pneumatic tyres, 120mm ground clearance, and an 18% gradeability rating, it handles the demands of mixed indoor/outdoor environments — from warehouse racking and loading docks to sealed outdoor yards and ramps — without needing a separate machine for each setting.
Its AC motors with regenerative braking keep energy consumption low, while mast options ranging from 3,000 mm up to 7,545 mm extended height give it genuine versatility across a wide range of racking configurations.
The choice of lead-acid or lithium-ION battery makes it adaptable to both single and multi-shift operations, and as a fully electric machine it's well suited to food production, manufacturing, and any facility where emissions, noise, or air quality are a consideration.
Is financing available for the Baoli KBE 20-25 electric forklift and what options are offered?
Yes financing is available for the KBE 20-25 electric forklift through Baoli Forklifts’ exclusive Australian distributor Linde Material Handling. You can learn more here in Linde MH’s Equipment Finance Options page. Financing options include rent-to-own, as well as leasing options such as short- and long-term rental.
What happens when the KBE 20-25 electric forklift needs servicing?
With the KBE 20-25 electric forklift, you will have the backing of Linde Material Handling Australia's nationwide support infrastructure. Linde MH’s qualified mobile technicians are all trained and graded specifically on Baoli products, supported by fully equipped workshops and spare parts stores in every capital city. Whether you're in Sydney, Melbourne, Brisbane, Perth, or Adelaide, local support is on hand when you need it.
